Yamaha DSP-AX1/RX-V1 User Manual

DSP-AX1/RX-V1
Schm
Ref. PART NO. Description
New Parts
*
Schm
Ref. PART NO. Description
New Parts
*
108
P.C.B. VIDEO
C29 UB245100 C.CE.M.CHP 0.1uF 25V
* C30 UU127470 C.EL 47uF 10V
* C31 UU127470 C.EL 47uF 10V
* C32 VJ900600 C.CE.M.CHP 30pF 50V
* C33 VJ900600 C.CE.M.CHP 30pF 50V
C34 UB245100 C.CE.M.CHP 0.1uF 25V
C35 UB052470 C.CE.M.CHP 470pF 50V
C36 UB052120 C.CE.M.CHP 120pF 50V
C37 UB044100 C.CE.M.CHP 0.01uF 50V
* C38 UU127470 C.EL 47uF 10V
* C39 UU147100 C.EL 10uF 25V
C40 UB052820 C.CE.M.CHP 820pF 50V
C41 VJ898700 C.CE.M.CHP 2pF 50V(ABG)
C41 VJ900200 C.CE.M.CHP 20pF 50V(UCRT)
* C42 VJ898800 C.CE.M.CHP 3pF 50V(ABG)
C42 VJ899900 C.CE.M.CHP 15pF 50V(UCRT)
* C43 UU166470 C.EL 4.7uF 50V
C44 UB052220 C.CE.M.CHP 220pF 50V
* C45 UU147100 C.EL 10uF 25V
* C46 VJ900600 C.CE.M.CHP 30pF 50V
C47 UB052470 C.CE.M.CHP 470pF 50V
* C48 UU166470 C.EL 4.7uF 50V
C49 VJ899900 C.CE.M.CHP 15pF 50V
C50 UB245100 C.CE.M.CHP 0.1uF 25V
C51 UB245100 C.CE.M.CHP 0.1uF 25V
C52 UB245100 C.CE.M.CHP 0.1uF 25V
C151 UP652470 C.POL 470pF 100V
C152 UP652470 C.POL 470pF 100V
C153 UP652470 C.POL 470pF 100V
C154 UP652470 C.POL 470pF 100V
C155 UP652470 C.POL 470pF 100V
C156 UP652470 C.POL 470pF 100V
C157 UP652470 C.POL 470pF 100V
C158 UP652470 C.POL 470pF 100V
C159 UP652470 C.POL 470pF 100V
C160 UP652470 C.POL 470pF 100V
C161 UP652470 C.POL 470pF 100V
C162 UP652470 C.POL 470pF 100V
C163 UP652470 C.POL 470pF 100V
C164 UP652470 C.POL 470pF 100V
C165 UP652470 C.POL 470pF 100V
C166 UP652470 C.POL 470pF 100V
C167 UP652470 C.POL 470pF 100V
C168 UP652470 C.POL 470pF 100V
C169 UP652470 C.POL 470pF 100V
C170 UP652470 C.POL 470pF 100V
C171 UB052100 C.CE.M.CHP 100pF 50V
C172 UB245100 C.CE.M.CHP 0.1uF 25V
C173 UB245100 C.CE.M.CHP 0.1uF 25V
* C174 UU129100 C.EL 1000uF 10V
* C175 UU127470 C.EL 47uF 10V
* C176 UU127470 C.EL 47uF 10V
* C201 UU166100 C.EL 1uF 50V
* C202 VZ001600 C.MYLAR 0.047pF 50V
* C203 VZ001600 C.MYLAR 0.047pF 50V
* C204 VZ001600 C.MYLAR 0.047pF 50V
* C205 VZ001600 C.MYLAR 0.047pF 50V
* C206 UU166100 C.EL 1uF 50V
* C207 UU137470 C.EL 47uF 16V
C208 VQ645600 C.MYLAR 100pF 50V
* C209 UU166100 C.EL 1uF 50V
C210 VQ645600 C.MYLAR 100pF 50V
* C211 UU166100 C.EL 1uF 50V
* C212 UU137470 C.EL 47uF 16V
C213 VZ002000 C.MYLAR 0.1uF 50V
C214 UA654220 C.MYLAR 0.022uF 50V
C215 UA654220 C.MYLAR 0.022uF 50V
C216 VZ002000 C.MYLAR 0.1uF 50V
* C217 UU137100 C.EL 10uF 16V
C218 VQ645600 C.MYLAR 100pF 50V
C219 VQ645600 C.MYLAR 100pF 50V
* C220 UU137100 C.EL 10uF 16V
* C221 UU137100 C.EL 10uF 16V
* C222 UU147220 C.EL 22uF 25V
* C223 UU147220 C.EL 22uF 25V
* C224 UU137100 C.EL 10uF 16V
* C225 UU137100 C.EL 10uF 16V
* C226 UU137100 C.EL 10uF 16V
* C227 UU137330 C.EL 33uF 16V
C228 FG212100 C.CE 100pF 50V
C229 FG212100 C.CE 100pF 50V
* C230 UU118100 C.EL 100uF 6.3V
* C231 UU118100 C.EL 100uF 6.3V
C232 FG212100 C.CE 100pF 50V
C233 FG212100 C.CE 100pF 50V
* C234 UU137330 C.EL 33uF 16V
* C235 UU139100 C.EL 1000uF 16V
C236 FG251220 C.CE 22pF 50V
C237 FG251220 C.CE 22pF 50V
* C238 UU139100 C.EL 1000uF 16V
C261 VF467000 C.CE.TUBLR 1000pF 50V
C262 VF467000 C.CE.TUBLR 1000pF 50V
C263 VF467000 C.CE.TUBLR 1000pF 50V
C264 VF467300 C.CE.TUBLR 0.01uF 16V
C381 VF466900 C.CE.TUBLR 470pF 50V
C382 VF467300 C.CE.TUBLR 0.01uF 16V
C383 VF466900 C.CE.TUBLR 470pF 50V
C384 VF467300 C.CE.TUBLR 0.01uF 16V
C921 UT452470 C.PP 470pF 100V
C922 UT452470 C.PP 470pF 100V
C925 UT452470 C.PP 470pF 100V
C926 UT452470 C.PP 470pF 100V
* C928 UU147100 C.EL 10uF 25V
C929 VR169200 C.MYLAR.ML ECQ-V1H474JL3
C930 VR169200 C.MYLAR.ML ECQ-V1H474JL3
* C931 UU147100 C.EL 10uF 25V
