Yamaha DSP-AX1/RX-V1 User Manual

DSP-AX1/RX-V1
Schm
Ref. PART NO. Description
New Parts
*
Schm
Ref. PART NO. Description
New Parts
*
109
P.C.B. VIDEO
C932 VR169200 C.MYLAR.ML ECQ-V1H474JL3
* C934 UU147100 C.EL 10uF 25V
C935 UT452470 C.PP 470pF 100V
C936 UT452470 C.PP 470pF 100V
* C939 V5376400 C.PP 100pF 100V
* C940 V5376400 C.PP 100pF 100V
C943 UB044100 C.CE.M.CHP 0.01uF 50V
C945 UB044100 C.CE.M.CHP 0.01uF 50V
C946 UB044100 C.CE.M.CHP 0.01uF 50V
* C954 V5376500 C.PP 220pF 100V
* C957 V5376500 C.PP 220pF 100V
* C960 V5376500 C.PP 220pF 100V
D1 iF004600 DIODE 1SS133
D2 iF004600 DIODE 1SS133
D4 iF004600 DIODE 1SS133
D5 iF004600 DIODE 1SS133
D6 VG435100 DIODE.ZENR MTZJ2.0B 2.0V
D7 iF004600 DIODE 1SS133
D8 iF004600 DIODE 1SS133
D9 iF004600 DIODE 1SS133
D10 iF004600 DIODE 1SS133
D11 iF004600 DIODE 1SS133
D12 iF004600 DIODE 1SS133
D13 iF004600 DIODE 1SS133
D201 VU264100 DIODE 1SR139-400
D202 VU264100 DIODE 1SR139-400
D901 VT332900 DIODE 1SS355
D902 VT332900 DIODE 1SS355
D903 VT332900 DIODE 1SS355
D904 VT332900 DIODE 1SS355
D905 VT332900 DIODE 1SS355
* IC1 XW911A00 IC LA7108M VIDEO AMP
IC4 XL493A00 IC TC74HC4051AP
IC5 XL493A00 IC TC74HC4051AP
IC6 XL493A00 IC TC74HC4051AP
IC7 XL493A00 IC TC74HC4051AP
IC8 iR405300 IC TC74HC4053AP
IC9 iR405300 IC TC74HC4053AP
* IC10 XW911A00 IC LA7108M VIDEO AMP
* IC11 XW911A00 IC LA7108M VIDEO AMP
* IC12 XW460A00 IC M35013-079SP
IC13 iG142200 IC TC74HCU04AP
IC14 iG142200 IC TC74HCU04AP
* IC15 XW416A00 IC BU2092 SER/PAR
IC201 XM356A00 IC NJM2068LD
IC202 XB247301 IC uPC4570HA
IC203 XP844A00 IC NJM4556AL
JK1 VU144900 CN.DIN 2P
JK2 VU144900 CN.DIN 2P
JK3 VU144900 CN.DIN 2P
JK4 VU144900 CN.DIN 2P
JK5 VU144900 CN.DIN 2P
JK6 VU144500 CN.DIN 2P
* JK261 V4164400 JACK.PHONE YKB21-5209
JK381 V2589500 CN 1P
L1 V2725700 COIL 15uH
L2 V3233700 COIL 1.5uH
* PJ151 V4806900 JACK.PIN 4P
* PJ152 V4806800 JACK.PIN 6P
* PJ153 V4806900 JACK.PIN 4P
* PJ154 V4806800 JACK.PIN 6P
PJ155 VU144200 JACK.PIN 1P
PJ381 VU459400 JACK.PIN 3P
* PJ901 V4583900 JACK.PIN 3P
* PJ902 V4583900 JACK.PIN 3P
* PJ903 V4583900 JACK.PIN 3P
* PJ904 V4583900 JACK.PIN 3P
* PJ905 V4548500 JACK.PIN 2P
* PJ906 V4548500 JACK.PIN 2P
* PJ907 V4912200 JACK.PIN 2P
* PJ908 V4806700 JACK.PIN 2P
* PJ909 V4806700 JACK.PIN 2P
* PJ910 V4548500 JACK.PIN 2P
* PJ911 V4548500 JACK.PIN 2P
Q1 iC174020 TR 2SC1740S R,S
Q2 iC174020 TR 2SC1740S R,S
Q3 iC287820 TR 2SC2878 A,B
Q4 iC174020 TR 2SC1740S R,S
Q5 iC174020 TR 2SC1740S R,S
Q6 VD678700 TR.DGT DTC114ES
Q7 iC174020 TR 2SC1740S R,S
Q8 iA101521 TR 2SA1015 Y
Q9 iC224030 TR 2SC2240 GR,BL
Q10 iC053540 TR 2SC535 A,B,C
Q11 iC224030 TR 2SC2240 GR,BL
Q12 iC287820 TR 2SC2878 A,B
Q151 iC174020 TR 2SC1740S R,S
Q201 VK432900 TR 2SD1915F S,T
Q202 VK432900 TR 2SD1915F S,T
Q901 VZ725900 TR 2SD1938F S,T
Q902 VZ725900 TR 2SD1938F S,T
Q903 VZ725900 TR 2SD1938F S,T
Q904 VZ725900 TR 2SD1938F S,T
Q905 VK432900 TR 2SD1915F S,T
Q906 VK432900 TR 2SD1915F S,T
Q907 VZ725900 TR 2SD1938F S,T
Q908 VZ725900 TR 2SD1938F S,T
Q909 VZ725900 TR 2SD1938F S,T
Q910 VZ725900 TR 2SD1938F S,T
Q911 VZ725900 TR 2SD1938F S,T
Q912 VZ725900 TR 2SD1938F S,T
Q913 VZ725900 TR 2SD1938F S,T
Q914 VZ725900 TR 2SD1938F S,T
Q915 VZ725900 TR 2SD1938F S,T
Q916 VZ725900 TR 2SD1938F S,T
Q917 VZ725900 TR 2SD1938F S,T
