DSP-AX1/RX-V1
Schm
Ref. PART NO. Description
New Parts
*
Schm
Ref. PART NO. Description
New Parts
*
110
P.C.B. VIDEO
Q918 VZ725900 TR 2SD1938F S,T
Q919 VZ725900 TR 2SD1938F S,T
Q920 VZ725900 TR 2SD1938F S,T
Q921 VZ725900 TR 2SD1938F S,T
* Q922 V5224700 TR 2SD1383K A,B
* Q923 VV655600 TR.DGT DTC143EKA TP
* Q924 VV655600 TR.DGT DTC143EKA TP
Q926 VZ725900 TR 2SD1938F S,T
Q927 VZ725900 TR 2SD1938F S,T
Q928 VZ725900 TR 2SD1938F S,T
R152 Vi199200 R.MTL.CHP 56KΩ 1/10W
R153 Vi199200 R.MTL.CHP 56KΩ 1/10W
R156 Vi199200 R.MTL.CHP 56KΩ 1/10W
R157 Vi199200 R.MTL.CHP 56KΩ 1/10W
R160 Vi199200 R.MTL.CHP 56KΩ 1/10W
R161 Vi199200 R.MTL.CHP 56KΩ 1/10W
R164 Vi199200 R.MTL.CHP 56KΩ 1/10W
R165 Vi199200 R.MTL.CHP 56KΩ 1/10W
R168 Vi199200 R.MTL.CHP 56KΩ 1/10W
R169 Vi199200 R.MTL.CHP 56KΩ 1/10W
R174 Vi199200 R.MTL.CHP 56KΩ 1/10W
R175 Vi199200 R.MTL.CHP 56KΩ 1/10W
R180 Vi199200 R.MTL.CHP 56KΩ 1/10W
R181 Vi199200 R.MTL.CHP 56KΩ 1/10W
R201 HV453330 R.CAR.FP 3.3Ω 1/4W
R206 HV453330 R.CAR.FP 3.3Ω 1/4W
R231 HV455220 R.CAR.FP 220Ω 1/4W
R239 HV455220 R.CAR.FP 220Ω 1/4W
R240 HV455100 R.CAR.FP 100Ω 1/4W
R243 HV455100 R.CAR.FP 100Ω 1/4W
R917 Vi194200 R.MTL.CHP 510Ω 1/10W
R918 Vi198200 R.MTL.CHP 22KΩ 1/10W
R919 Vi198200 R.MTL.CHP 22KΩ 1/10W
R920 Vi194200 R.MTL.CHP 510Ω 1/10W
R921 Vi194200 R.MTL.CHP 510Ω 1/10W
R922 Vi198200 R.MTL.CHP 22KΩ 1/10W
R923 Vi198200 R.MTL.CHP 22KΩ 1/10W
R924 Vi194200 R.MTL.CHP 510Ω 1/10W
R925 Vi194200 R.MTL.CHP 510Ω 1/10W
R926 Vi198200 R.MTL.CHP 22KΩ 1/10W
R927 Vi198200 R.MTL.CHP 22KΩ 1/10W
R928 Vi194200 R.MTL.CHP 510Ω 1/10W
R929 Vi198200 R.MTL.CHP 22KΩ 1/10W
R930 Vi194200 R.MTL.CHP 510Ω 1/10W
R931 Vi194200 R.MTL.CHP 510Ω 1/10W
R932 Vi198200 R.MTL.CHP 22KΩ 1/10W
R933 Vi198200 R.MTL.CHP 22KΩ 1/10W
R934 Vi194200 R.MTL.CHP 510Ω 1/10W
R936 Vi198200 R.MTL.CHP 22KΩ 1/10W
R937 Vi198200 R.MTL.CHP 22KΩ 1/10W
R939 Vi194100 R.MTL.CHP 470Ω 1/10W
R945 Vi194100 R.MTL.CHP 470Ω 1/10W
R951 Vi194100 R.MTL.CHP 470Ω 1/10W
R957 Vi194100 R.MTL.CHP 470Ω 1/10W
R961 Vi194100 R.MTL.CHP 470Ω 1/10W
R963 Vi194100 R.MTL.CHP 470Ω 1/10W
R970 Vi194100 R.MTL.CHP 470Ω 1/10W
R975 Vi194100 R.MTL.CHP 470Ω 1/10W
R991 Vi194100 R.MTL.CHP 470Ω 1/10W
R992 Vi194100 R.MTL.CHP 470Ω 1/10W
R995 Vi194100 R.MTL.CHP 470Ω 1/10W
R996 Vi194100 R.MTL.CHP 470Ω 1/10W
R999 Vi194100 R.MTL.CHP 470Ω 1/10W
* RY901 V4785600 RELAY DC AGN2004H
* RY902 V4785600 RELAY DC AGN2004H
* RY903 V4785600 RELAY DC AGN2004H
* RY904 V4785600 RELAY DC AGN2004H
* RY905 V4785600 RELAY DC AGN2004H
* RY906 V4785600 RELAY DC AGN2004H
* SW201 V4746100 SW.PUSH SPUN22 2
* SW202 V4104600 SW.RT.ENC SDB161PH20F-1-4-14
* SW351 V4757100 SW.TACT EVQ11A
* SW352 V4757100 SW.TACT EVQ11A
* SW353 V4757100 SW.TACT EVQ11A
* SW354 V4757100 SW.TACT EVQ11A
* SW355 V4757100 SW.TACT EVQ11A(UCA)
* SW356 V4757100 SW.TACT EVQ11A(UCA)
* SW357 V4757100 SW.TACT EVQ11A
* SW358 V4757100 SW.TACT EVQ11A
* SW359 V4757100 SW.TACT EVQ11A
* SW360 V4757100 SW.TACT EVQ11A(UCA)
* SW361 V4757100 SW.TACT EVQ11A(UCA)
* SW362 V4757100 SW.TACT EVQ11A
* SW363 V4757100 SW.TACT EVQ11A
* SW990 V5089500 SW.RT.ENC REB162(9X5)RVB
* SW991 V4859300 SW.RT.ENC
* VR201 V4104700 VR 16KΩ
* VR202 V4104800 VR 20KΩ
VR203 VU145000 VR MN30KΩ
XL1 VD980900 RSNR.CRYS 14.3181MHz(UCRT)
XL1 VV949900 RSNR.CRYS 17.734475MHz(ABG)
V3750100 PIN L=50
BB071360 SCR.TERM 8.3x13
