Operation
44
ECM00241
● Before tilting the outboard motor, stop
the engine by following the procedure
on page 40. Never tilt the outboard mo-
tor while the engine is running. Severe
damage from overheating can result.
● Do not tilt up the engine by pushing the
tiller handle (if equipped) because this
could break the handle.
EMU2797B
Procedure for tilting up (manual tilt
models)
1. Place the remote control lever / gear
shift lever in neutral.
2. Disconnect the fuel line from the out-
board motor.
3. Place the tilt lock lever (if equipped) in
the release/up position.
4. Pull up the shallow water lever (if
equipped).
5. Hold the rear of the top cowling with one
hand and tilt the engine up fully.
6. Push the tilt support knob into the clamp
bracket. Or the tilt support bar will turn to
the lock position automatically.
NOTICE: Do not use the tilt support
lever or knob when trailering the
boat. The outboard motor could
shake loose from the tilt support and
fall. If the motor cannot be trailered in
the normal running position, use an
additional support device to secure it
in the tilt position. For more detailed
information, see page 47.
[ECM01641]
