Yamaha EF5500EFW - Control Panel Components; AC Switch (N.F.B.) Operation; Fuel Tank Cap Usage

– 10 –
AC switch (N.F.B.)
The AC switch (Non-Fuse Breaker) turns off automati-
cally when the load exceeds the generator rated out-
put.
1 “I” (ON)
2 “3” (OFF)
å EF5500EFW/EF5500FW
∫ EF5500DFW
ç supplies AC 120 V (EF5500DFW)
∂ supplies AC 120 V and 240 V (EF5500DFW)
NOTICE
Reduce the load to the specified generator rated
output if the AC switch (N.F.B.) turns off. If it turns
off again, consult a Yamaha dealer.
1
2
763-252a
A
1
2
1
2
B
2
1
C
1
1
D
Fuel tank cap
Remove the fuel tank cap by turning it counterclock-
wise.
