Yamaha EF5500EFW - EF5500 FW Wiring Diagram

– 52 –
1 Rotor assembly
2 Sub coil
3 Main coil
4 Stator assembly
5 Voltage/hour meter
6 AC switch (N.F.B.)
7 AC receptacle
8 Engine switch
9 Rectifier
0 Condenser
q Oil warning unit
w Oil warning light
e Carburetor solenoid valve
r Charging coil
t TCI unit
y Spark plug
u Oil level switch
Color code
B Black
Br Brown
G Green
L Blue
O Orange
R Red
Y Yellow
B/W Black/White
G/R Green/Red
G/Y Green/Yellow
L/R Blue/Red
L/W Blue/White
å Except for Australia
∫ For Australia
G/Y
Br
R
G/Y
Br
R
L/W
L/R
G/R
R
Br
G
G
B
G/Y
G
G
B/W Y
B/W Y
L
B/W
G/Y
B/W
B
Y
L/R
O
B
BL O Y B/W
Br
R
Br
R
L/W
Y
B
G/R
1
2
4
5
6
7 7
8
0
q
w
r
t
y
u
e
3
9
7 7
∫
å
EF5500FW
