TRANSMISSION
ENG
NOTE:
NOTE:
NOTE:
EB413710
INSTALLING THE TRANSMISSION
1.Install:
 oil baffle plate
1
 crankcase breather hose
2
Insert the metal clamp
3
on the crankcase
breather hose into the slots
4
in the crank-
case.
2.Install:
 main axle assembly
1
 drive axle assembly
2
 oil seals
 circlips
 lock washer
 Make sure that the drive axle bearing cir-
clips
3
are inserted into the grooves
4
in
the upper crankcase.
 The main axle bearing pin
5
must face to-
wards the front of the crankcase and the
drive axle bearing pin
6
must face to-
wards the rear of the crankcase.
3.Check:
 transmission
Rough movement  Repair.
Oil each gear, shaft, and bearing thoroughly.

Yamaha fzs 600 1998 Specifications

General

Year	1998
Manufacturer	Yamaha
Model	FZS 600
Category	Motorcycle
Transmission	6-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Rear Tire	160/60-ZR17
Width	740 mm
Wheelbase	1, 440 mm
Displacement	599 cc
Ignition	Digital
Rear Suspension	Swingarm
Front Brakes	Dual 298 mm discs, 2-piston calipers
Rear Brakes	245 mm disc 1 piston caliper
Front Tire	120/70-ZR17
Height	1, 190 mm
Seat Height	790 mm
Fuel Capacity	18 liters
Engine Type	Liquid cooled, 4 stroke, transverse inline 4 cylinder, DOHC, 4 valves per cylinder
Bore x Stroke	62.0 x 49.8 mm / 2.4 x 2.0 inches
