7-40
30 Nm (3.0 mkg)
30 Nm (3.0 mkg)
7 Nm (0.7 mkg)
Order Job name/Part name Q’ty Remarks
1
2
3
4
5
Removing the front fork
Front wheel
Front brake calipers
Front fender
Bolt (upper bracket)
Cap bolt
Bolt (lower bracket)
Front fork assembly (left/right)
1
2
2
2
1/1
Remove the parts in the order listed.
Refer to “FRONT WHEEL AND BRAKE
DISCS” section.
Refer to “FRONT AND REAR BRAKES”
section.
Loosen
Loosen
Loosen
Refer to “REMOVING/INSTALLING THE
FRONT FORK LEGS” section.
For installation, reverse the removal
procedure.
NOTE:
Refer to
“REMOVING/
INSTALLING THE
FRONT FORK
LEGS” section.
NOTE:
NOTE:
FRONT FORK
CHAS
FRONT FORK
