ADJUSTING THE DRIVE CHAIN SLACK
CHK
ADJ
a
b
NOTE:
CAUTION:
NOTE:
a
b
NOTE:
EB304090
ADJUSTING THE DRIVE CHAIN SLACK
The drive chain slack must be checked at the
tightest point on the chain.
A drive chain that is too tight will over-
load the engine and other vital parts, and
one that is too loose can skip and dam-
age the swingarm or cause an accident.
Therefore, keep the drive chain slack
within the specified limits.
1.Stand the motorcycle on a level surface.
Securely support the motorcycle so that
there is no danger of it falling over.
Both wheels should be on the ground with-
out rider on the motorcycle.
2.Rotate the rear wheel several times and
check the drive chain to locate its tightest
point.
3.Check:
 drive chain slack
a
Out of specification  Adjust.
Drive chain slack
30  40 mm
4.Loosen:
 wheel axle nut
1
5.Adjust:
 drive chain slack
a. Loosen both locknuts
1
.
b. Turn both adjusting nuts
2
in direction
a
or
b
until the specified drive chain slack
is obtained.
Direction  Drive chain is
tightened.
Direction  Drive chain is
loosened.
 To maintain the proper wheel alignment,
adjust both sides evenly.
 Push the rear wheel forward to make sure
that there is no clearance between the
swingarm end plates and the ends of the
swingarm.
