9-3
FAULTY GEAR SHIFTING/
FAULTY CLUTCH PERFORMANCE
TRBL
SHTG
EB903000
FAULTY GEAR SHIFTING
HARD SHIFTING
Refer to “CLUTCH DRAGGING”.
SHIFT PEDAL DOES NOT MOVE
Shift shaft
 Improperly adjusted shift pedal link
 Bent shift shaft
Shift cam, shift fork
 Groove jammed with impurities
 Seized shift fork
 Bent shift fork guide bar
Transmission
 Seized transmission gear
 Jammed impurities
 Incorrectly assembled transmission
JUMPS-OUT-OF GEAR
Shift shaft
 Improperly adjusted shift lever position
 Improperly returned stopper lever
Shift fork
 Worn shift fork
Shift cam
 Improper thrust play
 Worn shift cam groove
Transmission
 Worn gear dog
EB904000
FAULTY CLUTCH PERFORMANCE
CLUTCH SLIPPING
Clutch
 Improperly adjusted clutch cable
 Loose clutch spring
 Fatigued clutch spring
 Worn friction plate/clutch plate
 Incorrectly assembled clutch
Engine oil
 Improper oil level
 Improper viscosity (low)
 Deterioration
CLUTCH DRAGGING
Clutch
 Warped pressure plate
 Unevenly tensioned clutch springs
 Bent push rod
 Broken clutch boss
 Burnt primary driven gear bushing
 Bent clutch plate
 Swollen friction plate
 Match marks not aligned
Engine oil
 Improper oil level
 Improper viscosity (high)
 Deterioration

Yamaha fzs 600 1998 Specifications

General

Year	1998
Manufacturer	Yamaha
Model	FZS 600
Category	Motorcycle
Transmission	6-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Rear Tire	160/60-ZR17
Width	740 mm
Wheelbase	1, 440 mm
Displacement	599 cc
Ignition	Digital
Rear Suspension	Swingarm
Front Brakes	Dual 298 mm discs, 2-piston calipers
Rear Brakes	245 mm disc 1 piston caliper
Front Tire	120/70-ZR17
Height	1, 190 mm
Seat Height	790 mm
Fuel Capacity	18 liters
Engine Type	Liquid cooled, 4 stroke, transverse inline 4 cylinder, DOHC, 4 valves per cylinder
Bore x Stroke	62.0 x 49.8 mm / 2.4 x 2.0 inches
