General Specifications
105
ProMix 01 User’s Guide
General Specifications
Frequency Response 20 Hz–20 kHz +1, –3 dB (@ +4 dB into 600 Ω )
THD Less than 0.1% (20 Hz–20 kHz @ +14 dB into 600 Ω )
Dynamic Range 105dB typ. (ST IN to ST OUT AD/DA converters)
Hum & Noise (20Hz–20kHz)*
Rs = 150 ohms. Input gain max.
Input pad = 0dB. Input sensitivity = –60dB.
–128dB Equivalent Input Noise
–88dB residual stereo output noise (ST OUT = OFF)
–88dB (92dB S/N) stereo output (ST OUT fader nominal, CH faders min.)
–64dB (68dB S/N) (ST OUT fader nominal, 1 channel fader at nominal)
Maximum Voltage Gain
76dB input channel to stereo output
76dB input channel to sends 3 & 4 (pre-fader)
12dB stereo input to stereo output
76dB input channel to monitor output (via ST bus)
Crosstalk (@1kHz)
–70dB adjacent input channels
–70dB input to output
Sampling Frequency 48 kHz
A/D Converter 20-bit linear 64-times oversampling
D/A Converter
Stereo Out 20-bit linear 8-times oversampling
Monitor out, SEND3, 4 18-bit linear 8-times oversampling
Processing
Internal 24-bit linear
EQ 36-bit linear
Signal Delay Less than 3.5ms (input channel to stereo output)
GAIN control 44dB (–60...–16dB) continuously variable
PAD 0/20dB attenuation
PAN 33-position
Parametric EQ
Low F= 32 Hz–1 kHz; G= ±15 dB; Q=1/6, 1/4, 1/3, 1/2, 3/4, 1, 3/2, 2, 3 oct, shelving
Mid F= 32 Hz–18 kHz; G= ±15 dB; Q=1/6, 1/4, 1/3, 1/2, 3/4, 1, 3/2, 2, 3 oct
High F= 1 kHz–18 kHz; G= ±15 dB; Q=1/6, 1/4, 1/3, 1/2, 3/4, 1, 3/2, 2, 3 oct, shelving
Effects Types Reverb, delay, chorus, symphonic, flange, pitch change, phasing, tremolo, auto pan
Compressor Types Compressor, Gate, Ducking
Faders
Type 60 mm motorized
Resolution +6dB...–66dB, –∞dB (128 position)
Memories
Scenes 50
Internal Effects 30 preset, 10 user
EQ Presets 30 preset, 20 user
COMP 10 preset, 10 user
LCD display 240 x 64 dot backlit graphic LCD display
Meters 2 × 12-segment LED bars
Power require-
ments
US & Canada model 120V AC, 60Hz
General model 230V AC, 50Hz
British model 240V AC, 50Hz
Power Consumption 70 W
Weight 12.5 kg (27.6 lb)
Dimensions (W × H × D) 435 × 124.7 × 487.4 mm (17.1" × 5" × 19.2")
Free-air operating temperature range 10˚C–35˚C (50˚F–95˚F)
Supplied Accessories Button protector
Optional Extras
Rack-Mount kit (RK01)
Wooden side panels (W01SP)
Carrying case
Color fader knob set (FK8R, G, B, W, Y)
* Hum & noise measured with a 6dB/octave 12.7kHz LPF, equivalent to a 20kHz filter with infinite dB/octave attenuation.
