Setting the CUE Mode
51
ProMix 01 User’s Guide
Setting the CUE Mode
CUE modes are set on the CUE LCD function, shown below. The
name of the current CUE mode is highlighted. The PARAMETER
wheel is used to select modes. When another mode is selected, its
name flashes. If it is activated by pressing [ENTER], it stops flashing,
appears highlighted, and becomes the current CUE mode.
CUE Signal Sources
The following table shows where the various CUE signals are sourced.
n/a: not applicable.
CUE/2TR IN Switch
This switch determines the signal source for the monitor output and
phones. CUE selects the CUE bus; 2TR IN selects the 2 TR IN inputs.
CUE is used for normal mixing operations. 2TR IN, for 2-track play-
back and confidence monitoring.
Channels
CUE Modes
GROUP LCD Function
MIX & LAST CUE
CH1–16 mono
Mono/pre-fader Mono/post-fader, pre-pan
CH1–16 stereo pair
Mono/pre-fader (L+R mix)
Mono/post-fader, pre-pan
(L+R mix)
Stereo input
Stereo/pre-fader Stereo/post-fader, pre-pan
RTN1, RTN2
Stereo/pre-fader n/a
SEND3, SEND4
Mono/pre-fader n/a
SEND3-4
Stereo/pre-fader n/a
Stereo output
Stereo/pre-fader n/a
1. Press [CUE].
The CUE LCD function
appears.
2. Use the PARAMETER wheel
to select a CUE mode.
3. Press [ENTER] to activate
the selected mode.
The name of the CUE mode
appears highlighted.
To Next Page
