Yamaha Programmable Mixer 01 - Preset Dynamics Processor Parameters

78 Chapter 8: Dynamics Processors
ProMix 01 User’s Guide
Preset Dynamics Processor Parameters
Type Program # Program Name Description Parameters
Threshold Ratio Attack Release Out Gain
–40...+18dB 1:1–∞:1 0–120ms 0.1–6.0s –18...+18dB
Comp
1 TOTAL COMP
Typical mix compression for
adding punch and definition.
0dB 2:1 50ms 3.0s +1dB
2 RADIO COMP Typical FM radio compression. +6dB 4:1 18ms 5.0s +3dB
3 COMP FAST
Fast attack compression to
catch all signal transients.
+2dB 4:1 5ms 2.5s +3dB
4 COMP SLOW
Slow attack compression to al-
low signal transients to pass
through unaffected.
–2dB 4:1 70ms 5.0s +1dB
5 COMP HEAVY1 Strong signal limiting. –3dB 10:1 14ms 0.5s +2dB
6 COMP HEAVY2 Medium signal limiting. 0dB 6:1 18ms 1.5s +3dB
Threshold Attack Hold Decay Range
–50...+10dB 0–120ms 3–341ms 85ms–10.9s 0...–80dB
Gate
7 GATE FAST Quick close noise gate. –6dB 1ms 101ms 1.3s –20dB
8 GATE SLOW Slow close noise gate. –2dB 5ms 315ms 8.2s –25dB
Threshold Attack Hold Decay Range
–50...+10dB 0–120ms 3–341ms 85ms–10.9s 0...–80dB
Duck
9 DUCKING Typical signal ducking –8dB 9ms 296ms 6.5s –9dB
10 BGM DUCKING
Ducking for background music
voice-overs.
–18dB 9ms 341ms 10.9s –14dB
