Yamaha Programmable Mixer 01 - Page 143

Add-20
ProMix 01 User’s Guide
5-3 All Control Change Assignment Table Bulk Dump Data Format
5-4 Setup Memory Bulk Dump Data Format
STATUS 11110000 F0 System Exclusive Message
ID No. 01000011 43 Manufacturer’s ID No. (YAMAHA)
SUB STATUS 0000xxxx 0n n=0-15(Tx/Rx Channel No.)
FORMAT No. 01111110 7E Universal Bulk Dump
BYTE COUNT(HIGH) 00010010 12 2314(96x6x2x2+10)bytes
BYTE COUNT(LOW) 00001010 0A
01001100 4C ‘L’
01001101 4D ‘M’
00100000 20 ‘ ‘
00100000 20 ‘ ‘
00111000 38 ‘8’
01000001 41 ‘A’
00110100 34 ‘4’
00110001 31 ‘1’
DATA NAME 01000011 43 ‘C’
MEMORY NO. 00100000 20 ‘ ‘
DATA*1 0xxxxxxx dsH Control Change Table(96x6x2x2bytes)*5
0xxxxxxx dsL
::
0xxxxxxx deH
0xxxxxxx deL
CHECK SUM*2 0xxxxxxx ee ee=(INVERT(‘L’+’M’+...+dsH+...+deL)+1) AND 7Fh
EOX 11110111 F7 End Of Exclusive
STATUS 11110000 F0 System Exclusive Message
ID No. 01000011 43 Manufacturer’s ID No. (YAMAHA)
SUB STATUS 0000xxxx 0n n=0-15(Tx/Rx Channel No.)
FORMAT No. 01111110 7E Universal Bulk Dump
BYTE COUNT(HIGH) 00000000 00 62(26x2+10)bytes
BYTE COUNT(LOW) 00111110 3E
01001100 4C ‘L’
01001101 4D ‘M’
00100000 20 ‘ ‘
00100000 20 ‘ ‘
00111000 38 ‘8’
01000001 41 ‘A’
00110100 34 ‘4’
00110001 31 ‘1’
DATA NAME 01010011 53 ‘S’
00100000 20 ‘ ‘
DATA*1 0xxxxxxx dsH Setup Memory(26x2bytes)*6
0xxxxxxx dsL
::
0xxxxxxx deH
0xxxxxxx deL
CHECK SUM*2 0xxxxxxx ee ee=(INVERT(‘L’+’M’+...+dsH+...+deL)+1) AND 7Fh
EOX 11110111 F7 End Of Exclusive
