Add-23
ProMix 01 User’s Guide
5-9 Key Remote Bulk Dump Data Format (Receive only)
5-10 Error/Warning Report Bulk Dump Data Format (Transmission only)
STATUS 11110000 F0 System Exclusive Message
ID No. 01000011 43 Manufacturer’s ID No. (YAMAHA)
SUB STATUS 0000xxxx 0n n=0-15(Rx Channel No.)
FORMAT No. 01111110 7E Universal Bulk Dump
BYTE COUNT(HIGH) 00000000 00 11(1+10)bytes
BYTE COUNT(LOW) 00001011 0B
01001100 4C ‘L’
01001101 4D ‘M’
00100000 20 ‘ ‘
00100000 20 ‘ ‘
00111000 38 ‘8’
01000001 41 ‘A’
00110100 34 ‘4’
00110001 31 ‘1’
DATA NAME 01001011 4B ‘K’
MEMORY NO. 0xxxxxxx Kn Key Number*11
DATA*1 0xxxxxxx DT Key Data*12
CHECK SUM*2 0xxxxxxx ee ee=(INVERT(‘L’+’M’+...+dsH+...+deL)+1) AND 7Fh
EOX 11110111 F7 End Of Exclusive
STATUS 11110000 F0 System Exclusive Message
ID No. 01000011 43 Manufacturer’s ID No. (YAMAHA)
SUB STATUS 0000xxxx 0n n=0-15(Tx Channel No.)
FORMAT No. 01111110 7E Universal Bulk Dump
BYTE COUNT(HIGH) 0xxxxxxx nn nn([Message]x2+10)bytes
BYTE COUNT(LOW) 0xxxxxxx nn
01001100 4C ‘L’
01001101 4D ‘M’
00100000 20 ‘ ‘
00100000 20 ‘ ‘
00111000 38 ‘8’
01000001 41 ‘A’
00110100 34 ‘4’
00110001 31 ‘1’
DATA NAME 01011000 58 ‘X’
01000101 45 ‘E’
DATA*1 0xxxxxxx EnH Message No.(HIGH)*13
0xxxxxxx EnL Message No.(LOW)
0xxxxxxx Ms Message*14
::
0xxxxxxx Me
CHECK SUM*2 0xxxxxxx ee ee=(INVERT(‘L’+’M’+...+dsH+...+deL)+1) AND 7Fh
EOX 11110111 F7 End Of Exclusive
