Chapter 4: Auxiliaries and Effects
ProMix 01 User’s Guide
Program 13—FLANGE->REVERB
Stereo flange followed by reverb.
Parameter Setting Range Description
Mod.Freq 1.4Hz 0.1–20.0Hz Flange modulation speed.
Mod.Depth 22% 0–100% Flange modulation depth. The amount of modulation.
FB.Gain +45% –99...+99% Feedback gain. The amount of processed signal fed back into the flanger.
Mod.Dly 13.0ms 0.0–15.5ms Flange modulation delay. The delay time before modulation starts.
Rev.time 2.4s 0.3–30.0s Reverb time.
Diffusion 8 0–10 Reverb diffusion.
Ini.Dly 26.0ms 0.1–160.0ms Reverb initial delay between the direct sound and early reverb reflections.
LPF 4.5kHz 1.0kHz–16.0kHz, THRU Reverb low pass filter cutoff frequency.
HPF 45Hz THRU, 32Hz–8kHz Reverb high pass filter cutoff frequency.
Rev.Depth 30% 0–100% Reverb depth. The amount of reverb.
Program 14—DELAY L-C-R
A three-part delay with independent delay time parameters for left, right, and center.
Parameter Setting Range Description
Dly(L) 250.0ms 0.1–661.0ms Left channel delay time.
Dly(R) 500.0ms 0.1–661.0ms Right channel delay time.
Dly(C) 125.0ms 0.1–661.0ms Center channel delay time.
Level(C) 70 0–100 Center delay volume level.
FB.Dly 500.0ms 0.1–661.0ms Feedback delay. The delay time before feedback starts.
FB.Gain +40% –99...+99% Feedback gain. The amount of delayed signal fed back into the delay.
High Ratio 0.8 0.1–1.0 Feedback high-frequency decay ratio.
Program 15—MONODLY->CHORUS
Mono delay followed by stereo chorus.
Parameter Setting Range Description
Delay 400.0ms 0.1–618.0ms Delay time.
FB.Gain +32% –99...+99% Delay feedback gain. The amount of delayed signal fed back into the delay.
High Ratio 0.6 0.1–1.0 Delay feedback high-frequency decay ratio.
Mod.Freq 0.4Hz 0.1–20.0Hz Chorus modulation speed.
Mod.Depth 10% 0–100% Chorus modulation depth. The amount of modulation.
Mod.Dly 0.1ms 0.0–24.0ms Chorus modulation delay. The delay time before modulation starts.
