AUDIO 5AUDIO 4
OPTICAL COAXIAL
CENTER FRONT
SURROUND
/ZONE B/BI-AMP
SPEAKERS
PRE OUT
SUBWOOFER
AUDIO 2
(3 MUSIC)
AUDIO 1
AUDIO 3
1
2
FRC FL SR SL
NOTE
(
To use the Zone speaker system, the speaker configuration settings must be changed.
(
You can also connect up to 2 subwoofers (with built-in amplifier) to the unit. Two subwoofers connected to the unit output the
same sounds.
(
When using only one subwoofer, you can place it either in the left or right side.
Related links
(
“Speaker requirements”(p.49)
(
“Setting your speaker system”(p.161)
(
“Playback in multiple rooms (zone function)”(p.123)
47
PREPARATIONS > How to place speakers (speaker systems)
