Cable requirements

Use the following types of commercially-available cables to connect speakers to the unit:

(

Speaker cables (for connecting the speakers)

–

(

Audio pin cable (for connecting a subwoofer)

Related links

“Connecting the speaker”(p.51)

PREPARATIONS > Connecting speakers
