Yamaha TSX-112 User Manual

USING OPTION MENU
20 En
X Performing DAB CLEAR and INIT SCAN
DAB CLEAR: Deletes all DAB station information and preset settings stored in the unit. After DAB CLEAR is
complete, the unit moves to the INIT SCAN functions automatically. Note that once DAB CLEAR is
performed, the deleted information and preset settings cannot be restored.
INIT SCAN: Performs the initial scan manually. Each time you perform INIT SCAN, the newly received
stations are added to the previously received stations.
*
After performing INIT SCAN, the unit airs the first station as stored in station.
X Using TUNE AID
TUNE AID: Measures reception strength of the received DAB signal (from 0 (none) to 100 (best)). Adjust the
DAB/FM antenna to find the best position to receive the DAB signal.
y
To check the frequency corresponding to the channel label, refer to “DAB frequency information” on page 13.
Using DAB option menu
1 Press OPTION.
2 Select desired option menu with
S/T.
3 Confirm with ENTER.
4 “Press ENTER” appears.
Press ENTER to perform
*
.
5 Exit option menu with OPTION.
1 Press OPTION.
2 Select TUNE AID.
3 Confirm with ENTER.
4 Switch the channel label.
5 Exit TUNE AID.
6 Exit option menu with OPTION.
OPTION
MENU
ENTER
ENTER
1 2
3
Remote control Remote controlRemote control
4 5
ENTER
Remote controlRemote control
OPTION
OPTION
MENU
ENTER
ENTER
1 2
3
Remote control Remote controlRemote control
MENU
ENTER
4 5
6
ENTER
OPTION
Remote control Remote controlRemote control

Yamaha TSX-112 Specifications

General

Impedance	6 Ω
Driver diameter	110 mm
Frequency range	- Hz
RMS rated power	30 W
Audio output channels	2.0 channels
AUX in	Yes
Bluetooth	No
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Dimensions (WxDxH)	457 x 174 x 181 mm
USB connector type	USB Type-A
Supported radio bands	DAB, DAB+, FM
Preset stations quantity	60
Built-in charger	-
Power source type	AC
Product color	Black
Apple docking compatibility	iPhone, iPod

Weight and Dimensions

Weight	5100 g
