9-25
9
fittings for an airtight seal. Tighten all fittings
securely to avoid the possibility of unfiltered
air entering the engine.
ECB02270
Never operate the engine with the air filter
element removed. Doing so would allow
unfiltered air to enter, causing rapid en-
gine wear and possible engine damage.
Additionally, the fuel injection system
would be affected, resulting in poor engine
performance and possible overheating.
1. Remove the center seat cushion. (See
page 5-15.)
2. Lift up the rubber damper, and then re-
move the center seat by removing the
bolts.
3. Remove covers A and B by removing the
quick fastener screws.
1. Rubber damper
2. Bolt
UBHF11E0.book Page 25 Friday, October 1, 2021 5:00 PM
