9-26
9
4. Remove the air filter case cover by un-
hooking the snap holders, and then rotat-
ing the cover up and pulling it away from
the pivot holders in the back.
5. Remove the air filter element.
1. Quick fastener screw
2. Cover A
3. Cover B
2
3
1
1. Snap holder
2. Air filter case cover
3. Pivot holder
2
3
3
1
1
