Yamaha WR450F 2021 - Page 146

FRONT BRAKE
4-18
Removing the front brake master cylinder
Order Job/Parts to remove Q’ty Remarks
Brake fluid
Drain.
Refer to “BLEEDING THE HYDRAULIC
BRAKE SYSTEM” on page 3-25.
1Brake lever 1
2 Union bolt 1
3 Copper washer 2
4 Front brake hose 1
5 Brake master cylinder reservoir cap 1
6 Brake master cylinder reservoir diaphragm 1
7 Front brake master cylinder float 1
8 Front brake master cylinder holder 1
9 Front brake master cylinder 1
5
6
7
2
3
4
8
9
1
30 N・m (3.0 kgf・m, 22 lb・ft)
6 N・m (0.6 kgf・m, 4.4 lb・ft)
6 N・m (0.6 kgf・m, 4.4 lb・ft)
1.5 N・m (0.15 kgf・m, 1.1 lb・ft)
9 N・m (0.9 kgf・m, 6.6 lb・ft)
