DESCRIPTION
1-5
EAM20086
DESCRIPTION
Designs and specifications of the vehicle are subject to change without notice. Therefore, please note
that the descriptions in this manual may be different from those for the vehicle you have purchased.
1
1413
1516
17
1819202122
5
68
7910
1211
3, 42
1. Clutch lever
2. Multi-function display
3. Engine trouble warning light “ ”
4. Fuel level warning light “ ”
5. Front brake lever
6. Throttle grip
7. Start switch
8. Radiator cap
9. Fuel tank cap
10.Engine stop switch
11.Taillight
12.Fuel tank
13.Headlight
14.Radiator
15.Coolant drain bolt
16.Rear brake pedal
17.Air filter
18.Drive chain
19.Shift pedal
20.Oil level check window
21.Starter knob
22.Front fork
