CYLINDER HEAD
5-21
Removing the cylinder head
Order Job/Parts to remove Q’ty Remarks
6 Oil passage plug 2
M
7 N・m (0.7 kgf・m, 5.2 lb・ft)
1st
3rd
4th
2nd
40 N・m (4.0 kgf・m, 30 lb・ft)
23 N・m (2.3 kgf・m, 17 lb・ft)
60˚
90˚
10 N・m (1.0 kgf・m, 7.4 lb・ft)
10 N・m (1.0 kgf・m, 7.4 lb・ft)
LT
6
6
