THROTTLE BODY
7-6
Removing the injector
Order Job/Parts to remove Q’ty Remarks
1 Fuel inlet pipe 1
2Injector 1
3Gasket 1
4 Throttle position sensor 1
5 Intake air pressure sensor 1
1
2
(2)
5
4
3
3.5 N・m (0.35 kgf・m, 2.6 lb・ft)
3.5 N・m (0.35 kgf・m, 2.6 lb・ft)
