VE2700-8

Fig. 1-1

Handwheel

SP device

Top cover seal plug

(for oiling)

Needle thread

take-up

Oil sight window

Presser spring regulator

Finger guard

Adjusting knob

Eye guard

Looper thread take-up

Belt cover (small)

Needle bar guard

Thread tension

spring cap

Needle thread

take-up guard

Feed graduations

Cylinder upper cover

Thread guide plate

Side cover

Front cover

1. Name of each part

Presser foot

Table of Contents2
Safety Instructions4
Name of each Part11
Installation12
Semi-Submerged Type14
Installing the Table Top Type15
Installing the Semi-Submerged Type15
Pulley and Belt16
Hanging the Belt17
Belt Cover17
Eye Guard and Finger Guard18
Thread Guide Plate18
Sewing Speed and Rotating Direction of the Pulley19
Lubrication20
Lubricating Oil20
Lubricating20
Changing Oil21
Checking and Replacing the Oil Filter21
Proper Operation22
Needle System22
Installing the Needles22
Threading23
Adjusting the Thread Tension25
Pressure of the Presser Foot25
Adjusting the Position of the Presser Foot25
Adjusting the Movement of the Differential Feed Dog26
Adjusting the Stitch Length27
Adjusting the Fabric Guide (VE2713-8F)28
Pressure of the Walking Presser Foot (VE2711-8F-WF1)29
Adjusting the Fabric Edge Guide (VE2711-8, -8F, VE2740PR-8F)29
Raising the Upper Feed Roller (VE2740PR-8F)30
Pressure of the Upper Feed Roller (VE2740PR-8F)30
SP Device31
Cleaning the Machine32
Adjustments33
Needle Thread Tension33
Top Cover Thread Tension34
Looper Thread Tension35
Position of the Looper Thread Take-Up35
Relation between the Needle and the Spreader36
Spreader36
Top Cover Thread Guide37
Top Cover Thread Eyelet37
Distance between the Needle and the Looper38
Using the Timing Gauge38
Height of the Needle39
Back-And-Forth Position of the Needle and the Looper39
Needle and Needle Guard40
Needle Guard (Rear)40
Needle Guard (Front)41
Height of the Feed Dog42
Removing the Presser Foot and Presser Foot Lift43
Toeing up and down the Presser Foot44
Adjusting the Walking Presser Foot (VE2711-8F-WF1)45
Feeding Amount of the Puller (VE2740PR-8F)46
Pressure of the Clutch Tension Spring (VE2740PR-8F)46
Specifications47
