Yamato VE2700-8 class User Manual

16
VE2700-8
5. Proper operation
5.7 Adjusting the movement of the differential feed dog
Fig. 5-10
Loosen the screw ①.
For gathering sewing, move the screw ① upward.
(Maximum normal differential ratio 1:1.4)
For stretching sewing, move the screw ① downward.
(Maximum reverse differential ratio 1:0.8)
When the center of the screw ① is aligned with the mark
②, the differential ratio is 1:1.
①
②
Before performing this work, ALWAYS turn the
power switch OFF and check that the motor has
already stopped.
ÃÁÕÔÉÏÎ
Gathering
Stretching
When the stitch length is 4.2 mm, the maximum normal
differential ratio is 1:1.2.

ÎÏÔÉÃÅ
