Yamato VE2700-8 class User Manual

37
VE2700-8
Model VE2711-1-8 VE2711-2-8F VE2713-2-8F VE2740PR-1-8F VE2740PR-2-8F
Description
High speed small cylinder bed
3-needle (2-needle) interlock
stitch machine for hemming
High speed small cylinder
bed 3-needle (2-needle)
interlock stitch machine
for covering
High speed small cylinder bed
3-needle interlock stitch machine
with puller for lace attachment
Dimensions 445 mm (L) × 270 mm (W) × 405 mm (H)
445 mm (L) × 320 mm (W)× 405 mm
(H)
Circumference
of Cylinder
180 mm
233 mm (including lower feed roller)
243 mm (including lower feed roller,
supplementary roller)
Weight 39 kg 45 kg
Stitch Type ISO 406, 407, 602, 605
Application
Hemming operation for knitted
material
Covering operation for
knitted material
Attaching elastic lace for panty
hose etc.
Sewing Speed Up to 4500sti/min (during intermittent operation)*
Stitch Length
1.4-4.2 mm
Number of stitches per inch (25.4 mm): 6-18 stitches
per 30 mm: 7-21 stitches
Needle System
UY × 128GAS
#10-14 (Standard #10)
UY × 128GAS
#10-14 (Standard #11)
UY × 128GAS #9-14
Needle Distance
3-needle: 4.8 mm, 5.6 mm, 6.4 mm
(2-needle: 4.0 mm)
3-needle: 4.8 mm, 5.6 mm, 6.4 mm
Needle Stroke 31 mm 33 mm 31 mm 33 mm
Presser Foot Lift
For needle distance of 5.6 mm (Presser foot (lower) in horizontal state)
with spreader: 5.0 mm, without spreader: 7.0 mm
Feed Regulation Lever type (or adjusting knob)
Differential Ratio 1:0.8-1:1.4 (Standard)
Differential Feed
Regulation
Lever type (adjustable with a screwdriver)
Lubrication Automatic lubrication by trochoid-shaped pump (in combination with splash lubrication)
Lubricating Oil YAMATO SF OIL 28
Capacity of
Oil Reservoir
800 ml
Installation Table top type or semi-submerged type (exclusive supporting board is necessary)
Compliance With
Regulation
Machinery directive, RoHS directive, Packing and packing waste directive
Noise Declaration
Lp
A
= 74.3 dB (A) (4500 sti/min)
Standard complied with: ISO 10821-C6.2, ISO 11204 GR2
7. Specifications
*
Intermitted operation: Actual running time is less than 75% of operation time per 1 cycle. If actual running time is over
75% of operation time per 1 cycle, run a machine at 10% lower than the maximum sewing speed.
