47
No. Part No. Name Specification
1 GB70-85 Socket Head Cap Screw M6×30
2 CL6132-04-06 Plug-Oil Inlet
3 CD6236-04-19 Cover Dress
4 CD6236/6240-04-15 Headstock Cover(360/410)
5 CD6236/6240-04-14 Packing(360/410)
6 GB879-85 Spring Pin 5×30
7 GB70-85 Socket Head Cap Screw M5×16
8 CD6236-04-74 Bracket
9 CL6132-04-03 Plug
10 GB3452.1-82 O-Ring 14×2.65
11 CD6236-04-22 Fork
12 CD6236-04-21 Lever
13 CL6132-04-76 Fork
14 CD6236-04-20 Shaft
15 CD6236/6240-04-16 Headstock(360/410)
16 Q/ZB285.3 Oil Plug ZG 3/8"
17 GB70-85 Screw M12×20
18 CD6236-04-73 Limited Bracket
19 CL6132-04-82 Adjust Screw
20 CL6132-04-40 Plug
21 GB3452.1-82 O-Ring 19×2.65
22 CD6236-04-13 Plate
23 GB1160.1-86 Oil Sight 16
24 GB80-85 Fix Screw M6×10
25 Cl6132-04-99 Sleeve
26 GB77-85 Screw M8×12
27 GB2089-80 Spring 1×5×22
28 GB308-84 Steel Ball 6.5
29 CD6236-04-18 Bracket
30 CD6236-04-17 Gear Mn=2.5 Z=43
31 GB818-85 Cross Recessed Head Screw M3×15
32 GB812-88 Nut M30×1.5
33 GB858-88 Toothed Lock Washer 30
34 CD6236-04-02 Belt Pulley
35 RUN6246-101009 Spacer
36 Oil Seal TC55×42×9
37 GB70-85 Socket Head Cap Screw M6×40
38 GB1235-76 O-Ring 36×3.5
39 RUN6246-101010 Bearing Cover
40 RUN6246-101010-1 Packing
Instructions Manual for CL-38 (L190)
