48
No. Part No. Name Specification
41 GB1096-79 Key 8×40
42 GB1096-79 Key 8×50
43 CD6236-04-01 Shaft
44 GB278-89 Ball Bearing 80206
45 CD6236-04-03 Gear Mn=2.5 Z=38
46 CD6236-04-04 Gear Mn=2.5 Z=33
47 CD6236-04-05 Sleeve
48 CD6236-04-06 Gear Mn=2.5 Z=23
49 CD6236-04-07 Gear Mn=2.5 Z=33
50 GB278-89 Ball Bearing 80205
51 GB894.1-86 External Circlip 25
52 CD6236-04-08 Plug
53 GB70-85 Socket Head Cap Screw M6×14
54 CD6236-04-68 Cover
55 CD6236-04-67 Packing
56 GB278-89 Ball Bearing 80305
57 CD6236-04-69 Spacer
58 CD6236-04-09 Shaft
59 GB894.1-86 External Circlip 65
60 CD6236-04-63 Gear Mn=2.5 Z=39
61 CD6236-04-64 Gear Mn=2.5 Z=54
62 CD6236-04-65 Gear Mn=2.5 Z=47
63 GB1096-79 Key 8×60
64 CD6236-04-66 Gear Mn=2.5 Z=31
65 GB894.1-86 External Circlip 30
66 GB276-89 Ball Bearing E206
67 GB894.1-86 External Circlip 45
68 CD6236-04-10 Gear Mn=2.5 Z=60
69 GB1096-79 Key 8×30
70 CD6236-04-11 Gear Mn=2.5 Z=21
71 GB893.1-86 External Circlip 62
72 GB1235-76 O-Ring 56×3.5
73 CD6236-04-12 Cover
74 CD6236-04-62 Balance Piece
75 GB77-85 Fix Screw M6×8
76 CD6236-04-61 Set Nut
77 GB70-85 Socket Head Cap Screw M6×25
78 GB77-85 Fix Screw M6×10
79 CD6236-04-58 Cover
80 CD6236-04-59 Packing
Instructions Manual for CL-38 (L190)
