49
No. Part No. Name Specification
81 CD6236-04-60 Cycle Oil Ring
82 GB276-89 Ball Bearing E213
83 CD6236-04-57 Sleeve
84 CD6236-04-56 Gear Mn=2 Z=48
85 CD6236-04-34 Fix Black
86 CD6236-04-33 Set Nut
87 GB297-84 Taper Roller D2007114E
88 GB894.1-86 External Circlip 75
89 CD6236-04-35 Gear Mn=2.5 Z=43
90 CD6236-04-36 Gear Mn=2.5 Z=82
91 GB297-84 Taper Roller D2007116E
92 CD6236-04-38 Packing
93 CD6236-04-37 Cover
94 GB70-85 Socket Head Cap Screw M6×30
95 CD6236-04-39 Spindle D1-6
96 RUN6246-101082-1 Spring
97 RUN6246-101081 Cam Lock
98 RUN6246-101082 Cam Lock Stud
99 RUN6246-101087 Screw
100 GB1235-76 O-Ring 28×3.1
101 CD6236-04-40 Shaft
102 GB1096-79 Key 5×20
103 CD6236-04-43-1 Gear Mn=2 Z=24
104 GB894.1-86 External Circlip 42
105 CD6236-04-43-2 Bush
106 CD6236-04-44 Gear Mn=2 Z=48
107 CD6236-04-42-2 Bush
108 CD6236-04-42 Gear Mn=2 Z=36
109 CD6236-04-41 Spacer
110 GB894.1-86 External Circlip 22
111 GB278-89 Ball Bearing 80104
112 GB1096-79 Key 8×115
113 CD6236-04-45 Shaft
114 CD6236-04-46 Gear Mn=2 Z=26
115 CD6236-04-47 Sleeve
116 CD6236-04-48 Gear Mn=2 Z=24
117 CD6236-04-49 Gear Mn=2 Z=48
118 GB278-89 Ball Bearing 80204
119 GB1235-76 O-Ring 46×3.5
120 CD6236-04-55 Cover
Instructions Manual for CL-38 (L190)
