50
No. Part No. Name Specification
121 GB70-85 Socket Head Cap Screw M6×12
122 CD6236-04-54 Spacer
123 CD6240-04-53 Change Gear(410) Inch(24T)
124 GB70-85 Socket Head Cap Screw M6×14
125 CD6236-04-52 Cover
126 CD6236-04-52 Packing
127 HG4-692-67 Oil Seal SD25×40×10
128 GB278-89 Ball Bearing 80105
129 GB1096-79 Key 6×14
130 CD6236-04-50 Shaft
131 CD6236-04-51 Gear Mn=2 Z=36
132 GB894.1-86 External Circlip 20
133 CD6236-05-63A Lever
134 CD6236-04-28 Lever Head
135 CD6236-04-27 Lever Head
136 CL6132-04-62 External Circlip
137 CD6236-04-29 Shaft
138 GB77-85 Fix Screw M12×10
139 GB2089-80 Spring 0.9×9×40
140 GB308-84 Steel Ball φ10
141 GB3452.1-82 O-Ring 14×2.65
142 CD6236-04-31 Bracket
143 CD6236-04-30 Lever
144 CD6236-04-32 Fork
145 Cl6132-04-90 Plate
146 CD6236-04-26 Cover
147 GB1096-79 Key 4×10
148 GB2089-80 Spring 0.9×9×35
149 CD6236-04-25 Bracket
150 CD6236-04-24 Lever
151 CD6236-04-23 Fork
152 GB827-86 Rivet 2×5
153 CD6236-04-78A Lever
154 CL6132-04-68 Cover
155 GB1096-79 Key 5×18
156 CD6236-04-77 Gear Shaft Mn=1.5 Z=37
157 GB3452.1-82 O-Ring 10×2.65
158 CD6236-04-75 Lever Shaft
159 CL6132-04-91 Lever Bracket
160 CL6132-04-92 Plate
Instructions Manual for CL-38 (L190)
