No. Part No. Name Specification
1 GB70-85 Socket Head Cap Screw M6×16
2 CD6236-05-91 Cover
3 CD6236-05-65 Packing
4 CD6236-05-42 Gear Box Casting
5 GB70-85 Socket Head Cap Screw M8×60
6 GB118-86 Taper Pin A8×90
7 CD6236-05-58 Top Plate
8 GB70-85 Socket Head Cap Screw M5×20
9 CD6236-05-96 Fork
10 GB879-86 Spring Pin 3×10
11 CD6236-05-56 Fork
12 GB2089-80 Spring 0.8×5×17
13 GB308-84 Steel Ball 6
14 CD6236-05-92 Plate
15 CD6236-05-97 Plate
16 CD6236-05-95 Fork
17 CD6236-05-94 Fork
18 CD6236-05-55 Fork
19 CD6236-05-57 Drive Plate
20 CD6236-05-59 Sleeve
21 CD6236-05-51 Set Screw M6×5
22 GB70-85 Socket Head Cap Screw M6×35
23 GB70-85 Socket Head Cap Screw M6×16
24 CD6236-05-54 Fork
25 CD6236-05-89 Selector Bar
26 GB93-87 Spring Washer 6
27 GB70-85 Socket Head Cap Screw M6×16
28 GB879-86 Spring Pin 5×18
29 CD6236-05-53 Fork
30 CD6236-05-52 Screw
31 GB819-85 Cross Screw M5×8
32 GB3289.2-82 Oil Inlet Pip ZG1/2"
33 CD6236-05-87 Packing
34 GB3289.31-82 Plug ZG1/2"
35 CD6236-05-48 Cover
36 GB1160.1-89 Oil Sight Glass 20
37 GB70-85 Socket Head Cap Screw M6×35
38 CD6236-05-62 Plate
39 GB1096-79 Key 8×28
40 CD6236-05-01 Shaft
