No. Part No. Name Specification
41 HG4-692-67 Oil Seal PD20×35×10
42 GB70-85 Socket Head Cap Screw M6×16
43 CD6236-05-11 Bracket
44 CD6236-05-64 Packing
45 GB290-64 Roller Bearing 943/20
46 CD6236-05-12 Washer
47 GB894.1-86 Circlip 20
48 CD6236-05-13 Gear Mn=2.25Z=39Mn=1.75 Z=20
49 CD6236-05-14 Shaft
50 GB1096-79 Key 5×8
51 GB276-84 Ball Bearing 7000104
52 CD6236-05-15 Gear Mn=1.5 Z=38
53 CD6236-05-22 Gear Mn=2. Z=23 Mn=1.5 Z=19
54 GB894.1-86 Circlip 20
55 CD6236-05-27 Washer
56 GB893.1-86 Circlip 40
57 GB276-82 Ball Bearing 203
58 CD6236-05-28 Clutch
59 CD6236-05-76 Washer
60 GB894.1-86 Circlip 14
61 CD6236-05-29 Clutch Gear
62 GB894.1-86 Circlip 20
63 CD6236-05-31 Washer
64 CD6236-05-32 Packing
65 CD6236-05-33 Cover
66 GB70-85 Socket Head Cap Screw M6×16
67 HG4-692-67 Oil Seal PD20×35×10
68 CD6236-05-30 Shaft
69 CD6236-05-40 Fork
70 CD6236-05-88 Lever
71 GB308-84 Steel Ball φ6.5
72 GB2089-80 Spring 0.8×5×17
73 CD6236-05-90 Shaft
74 GB1096-79 Key 4×12
75 CD6236-05-101 Sleeve
76 GB3452.1-82 O-Ring 16×2.65
77 CD6236-05-63A Lever
78 CD6236-05-63 Lever
79 CL6132-04-90 Plate
80 GB77-85 Screw M6×6
