57
No. Part No. Name Specification
81 GB879-86 Spring Pin 4×25
82 CD6236-05-100 Washer
83 GB70-85 Socket Head Cap Screw M5×12
84 GB276-84 Ball Bearing 7000104
85 CD6236-05-67 Shaft
86 CD6236-05-66 Washer
87 CD6236-05-68 Gear Mn=1.75Z=30 Mn=2.25 Z=19
88 CD6236-05-69 Washer
89 GB894.1-86 Circlip 25
90 GB276-84 Ball Bearing 7000104
91 CD6236-05-16 Gear Mn=2 Z=22
92 CD6236-05-17 Gear Mn=1.5 Z=19
93 CD6236-05-18 Gear Mn=2. Z=20
94 CD6236-05-19 Gear Mn=2 Z=24
95 CD6236-05-20 Gear Mn=2 Z=23
96 CD6236-05-21 Gear Mn=1.5 Z=27
97 CD6236-05-23 Gear Mn=1.5 Z=24
98 CD6236-05-24 Gear Mn=1.75 Z=28
99 CD6236-05-25 Gear Mn=1.75 Z=26
100 CD6236-05-26 Gear Mn=1.5 Z=38
101 CD6236-05-27 Washer
102 GB276-82 Ball Bearing 203
103 CD6236-05-77 Nut
104 CD6236-05-79 Gear Mn=1.5 Z=33
105 CD6236-05-81 Bracket
106 GB70-85 Socket Head Cap Screw M6×16
107 GB1096-79 Key 5×35
108 GB893.1-86 Circlip 40
109 GB77-85 Screw M5×8
110 GB894.1-86 Circlip 22
111 HG4-692-67 Oil Seal PD25×40×10
112 GB301-84 Thrust Bearing 8105
113 CD6236-05-78 Shaft
114 CD6236-05-41 Fork
115 GB276-84 Ball Bearing 7000104
116 GB1096-79 Key 5×16
117 CD6236-05-71 Shaft
118 CD6236-05-70 Gear Mn=2.25 Z=22
119 GB894.1-86 Circlip 20
120 CD6236-05-72 Gear Mn=2 Z=22
Instructions Manual for CL-38 (L190)
