63
No. Part No. Name Specification
1 GB818-85 Screw M4×10
2 CD6236-06-03 Name Plate
3 GB70-85 Socket Head Cap Screw M8×60
4 CD6236-06-01 Apron Casting
5 GB117-86 Pin B8×60
6 CD6236-06-31 Lever
7 CD6236-06-51 Bolt
8 CD6236-06-39 Stopper
9 GB70-85 Socket Head Cap Screw M5×16
10 GB5782-86 Bolt M6×12
11 CD6236-06-38 Half Bracket
12 CD6236-06-52 Half Nut(Inch) 4TPI
13 CD6236-06-30 Gib
14 GB5782-86 Bolt M6×10
15 GB79-85 Socket Head Set Screw M5×6
16 GB894.1-86 Clip 30
17 CD6236-06-35 Key
18 GB290-82 Needle Bearing 7943/30
19 CD6236-06-28 Washer
20 GB301-84 Thrust Bearing 8106
21 CD6236-06-29 Gear-Drive Level Mn=1.75 Z=23
22 GB70-85 Socket Head Cap Screw M6×16
23 RUN6246-106059 Switch Brackek
24 RUN6246-106053 Bracket
25 RUN6246-106055 Pin
26 GB77-85 Socket Head Set Screw M6×6
27 CD6236-06-44 Shaft
28 GB3452.1-82 O-Ring 11.2×2.65
29 CD6236-06-19 Shaft
30 CD6236-06-50 Gear Mn=1.5 Z=18
31 GB894.1-86 External Circle 16
32 CD6236-06-33 Spindle Control Lever
33 Z16-1 Lever Bush
34 GB1160-86 Sight Glass B20
35 CD6236-06-49 Packing
36 CD6236-06-48 Bottom Plate
37 GB70-85 Socket Head Cap Screw M5×16
38 Q/ZB285.3 Oil Plug R 3/8"
39 CD6236-06-37 Pin
40 CD6236-06-25 Shaft
Instructions Manual for CL-38 (L190)
