YANGZHOU SUPER MACHINE TOOL CD6240 - Page 64

64
No. Part No. Name Specification
41 GB879-86 Spring Pin 5×42
42 CD6236-06-26 Lever Head
43 CD6236-06-27 Handle
44 GB308-84 Steel Ball φ6.5
45 GB896-86 Clip 8
46 GB77-85 Socket Head Cap Screw M8×6
47 CD6236-06-43 Cover
48 CD6236-06-42 Packing
49 CD6236-06-41 Fork
50 GB3452.1-82 O-Ring 25.8×3.55
51 CD6236-06-22 Sleeve
52 GB3452.1-82 O-Ring 16×1.8
53 CD6236-06-21 Shaft
54 GB827-86 Rivet 2×6
55 GB818-85 Screw M4×10
56 GB879-86 Spring Pin 4×30
57 CD6236-06-18-02 Input Bush
58 CD6236-06-45 Gear-Drive Bevel Mn=1.75 Z=64
59 GB1096-79 Key 5×12
60 CD6236-06-47 Gear Mn=1.5 Z=18
61 GB879-86 Spring Pin 5×22
62 GB818-85 Screw M6×20
63 CD6236-06-46 Washer
64 GB3452.1-82 O-Ring 11.2×2.65
65 CD6236-06-18-01 Shaft
66 CD6236-06-17 Gear Mn=1.5 Z=18
67 CD6236-06-11 Gear Mn=1.5Z=80 Mn=1.25 Z=60
68 GB119-86 Pin D4×20
69 CD6236-06-12 Gear Mn=1.5Z=72 Mn=1.25 Z=60
70 GB879-86 Spring Pin 5×22
71 CD6236-06-15 Sleeve
72 CD6236-06-40 Gear Shaft Mn=1.5 Z=14
73 CD6236-06-34 Gear Mn=1.5Z=18 Mn=1.25 Z=60
74 CD6236-06-13 Shaft
75 CD6236-06-14 Lever Head
76 GB70-85 Socket Head Cap Screw M5×40
77 CD6236-06-16 Lever
78 GB1096-79 Key 6×18
79 CD6236-06-10 Shaft Mn=1.75 Z=16
80 CD6236-06-09 Gear Mn=1.5 Z=81
04/03/2020
Instructions Manual for CL-38 (L190)
64
