PRODUCT OVERVIEW
16 YM Series Operation Manual
NAMEPLATES
The nameplates of Yanmar YM series
engines are shown in Figure 7. Check the
engine’s model, output, min
-1
and serial
number on the nameplate. Please replace
if damaged or lost.
The engine nameplate is attached to the
engine rocker arm cover.
Figure 7
The marine gear nameplate (Figure 8) is
attached to the marine gear. Check the
marine gears model, gear ratio, oil used,
oil quantity and serial number.
Figure 8
The sail drive nameplate (Figure 9) is
attached to the sail drive. Check the sail
drive model and serial number.
Figure 9
129670-07201
Continuous power kW
Speed of prop.shaft
Gear Model
ｍｉｎ
-１
Fuel stop power kW
MFG.DATE
ｍｉｎ
-１
/
/
ｍｉｎ
-１
Model
ENG.No.
/
kW
㻹㻻㻰㻱㻸
㻹㻲㻳㻚㻌㻺㻻㻚
㻳㻱㻭㻾㻌㻾㻭㼀㻵㻻
㻻㻵㻸㻌
177524-02903
㻹㻲㻳㻚㻺㼛㻚
㻼㻭㻿㻿㻱㻰
㻹㻭㻾㻷
㻹㻻㻰㻱㻸
196420-02124
