SYSTEM DIAGRAMS
94 YM Series Operation Manual
WIRING DIAGRAMS
Color Coding
RRed
BBlack
WWhite
LBlue
RB Red / Black
LB Blue / Black
YW Yellow / White
YG Yellow / Green
WL White / Blue
V Purple
BW Blue / White
O Orange
WBr White / Brown
Allowable Length by Cross Sectional Area of
Battery Cable
Section of Cable
mm
2
(in.
2
)
Allowable Length
L = 1 + 2 + 3 m (ft)
15 (0.023) < 0.86 (0.26)
20 (0.031) < 1.3 (0.40)
30 (0.046) < 2.3 (0.70)
40 (0.062) < 2.8 (0.85)
50 (0.077) < 3.5 (1.07)
60 (0.093) < 4.1 (1.25)
