PERIODIC MAINTENANCE
52 YM Series Operation Manual
Tightening Fasteners
Use the correct amount of torque when you tighten fasteners on the engine. Applying
excessive torque may damage the fastener or component and not enough torque may
cause a leak or component failure.
he tightening torque in the Standard Torque Chart should be applied only to the
bolts with a “7” head (JIS strength classification: 7T). Apply 60% torque to bolts
that are not listed. Apply 80% torque when tightened to aluminum alloy.
Bolt Diameter x
Pitch (mm)
M6x1.0 M8x1.25 M10x1.5 M12x1.75 M14x1.5 M16x1.5
Tightening
Torque
N·m 11.0 ± 1.0 26.0 ± 3.0 50.0 ± 5.0 90.0 ± 10.0 140.0 ± 10.0 230.0 ± 10.0
ft-lb 8.0 ± 0.7 19.0 ± 2.1 37.0 ± 3.6 66.0 ± 7.2 103 ± 7.2 170 ± 7.2
