X K 3 1 9 0 A23p
(25)
Tare weight
1 symbol (+or-)
27 tare weight value ( 6 bit
Comman
d C
8number of decimal digits ( 04
Composed by 14 groups
of data per frame
Net weight
1 symbol (+or-)
27 tare weight value ( 6 bit
Comman
d D
8number of decimal digits ( 0
4
Composed by 14 groups
of data per frame
Unit price
16 unit price 6bit
Comman
d E
7 fix number of the decimal
digits 2
Composed by 13 groups
of data per frame
Amount
16 amount6bit
Comman
d F
7 fix number of the decimal
digits 2
Composed by 13 groups
of data per frame
Chapter7 Information Indication
1. Err 03 Overload alarming, need remove parts of the load or all of the load.
2. Err 05 AD part fault, please examine and dispose as following method
1.Examine sensor and its connecting wire.
2.AD part broken, please send back to factory for repairing.
3. Err 08 Parameter input is not meet the requirements, please input parameter
again
4. Err 09 Not meet the requirement of accumulate count /print’s request :not
stable or no zero operation.
5. Err 10 Unit weight is too small, count function is stop, and weight will be
locked.
