X K 3 1 9 0 –A23p
(1)
Chapter 1 Technical Parameter
1. Model : XK3190-A23p
2. Accuracy class : Class
3. A/D conversion mode: ∑-Δ
4.A/D conversion resolution： 1 million yard
5. A/D conversion speed： 10 times/second
6. Load excitation voltage : DC 5V
7. Signal source: 1 load cell（four line mode）
8. Input signal range： -16 mV ～18mV
9.Display: 6+6+6 digits LCD, 6 state indication symbol,3 class
battery power prompting
10. Keypad: 4×6 membrane key
11. Power supply: AC 220V/50 Hz
12. DC power : built-in rechargeable 6V/5AH battery
13. Fuse: 0.5A
14. Warm-up time : 15～30 minutes
15.Operation temperature： 0～40℃
16.Storage temperature： -25℃～55℃
17.External dimensions: 264×174×172(mm)
18.Net weight : about 2.2kg
