Yaohua Weighing System XK3190-A23p - Chapter 2 Installation; Front and Back Panel Functions

X K 3 1 9 0 –A23p
(2)
Chapter2 Installation
1. A23p weighing indicator front side function instruction and back side
function instruction:
(picture 2-1-1 ) Front side function instruction
(picture 2-1-2 ) B
ack side function instruction
Load
cell
Communication
port
fuse
AC
Power Switch
Calibration
Battery
