1pc. (1124) - Vent Roof Peak FSC 50.8 x 88.9 x 2235.2mm (88") Y70229-1124
4pc. (1152) - Side Wall Panel FSC 41.3 x 1073.2 x 762mm (30") Y70229-1152
2pc. (1125) -
Part Identification ( )
assembly. Actual dimensions may be smaller or larger.
Dimensions are approximate and are shown to assist in the identification of parts for
Y50229-1110
Mid Post FSC 66.7 x 76.2 x 1835.2mm (72-1/4")
2pc. (1110) -
Y50229-1118
Side Base FSC 38.1 x 76.2 x 2190.8mm (86-1/4")
2pc. (1118) -
Y50229-1107
Side Wall Sill FSC 38.1 x 101.6 x 1112.8mm (43-13/16")
4pc. (1107) -
Y50229-1114
Middle Roof Rafter FSC 66.7 x 76.2 x 1079.5mm (42-1/2")
5pc. (1114) -
1pc. (1123) - Roof Peak FSC 50.8 x 88.9 x 2235.2mm (88") Y70229-1123
Side Wall Top FSC 44.5 x 114.3 x 2235.2mm (88") Y70229-1125
4pc. (1144) -
Short Post Assembly FSC 66.7 x 76.2 x 1047.8mm (41-1/4")
Y70229-1144
