Front Wall Sill FSC 38.1 x 101.6 x 503.4mm (19-13/16")
Y50229-1105
2pc. (1115) -
Right Roof Rafter FSC 66.7 x 76.2 x 1079.5mm (42-1/2")
Y50229-1115
2pc. (1116) -
Part Identification ( )
assembly. Actual dimensions may be smaller or larger.
Dimensions are approximate and are shown to assist in the identification of parts for
Y50229-1108
Left Post FSC 66.7 x 76.2 x 1835.2mm (72-1/4")
2pc. (1108) -
Y50229-1109
Right Post FSC 66.7 x 76.2 x 1835.2mm (72-1/4")
2pc. (1109) -
Y50229-1111
Left Door Post FSC 38.1 x 66.7 x 1974.9mm (77-3/4")
1pc. (1111) -
Y50229-1112
Right Door Post FSC 38.1 x 66.7 x 1974.9mm (77-3/4")
1pc. (1112) -
1pc. (1119) - Front Base FSC 38.1 x 66.7 x 1905mm (75") Y50229-1119
Y50229-1143
Front Gable Beam FSC 66.7 x 76.2 x 1192.2mm (46-15/16")
1pc. (1143) -
Y50229-1116
Left Roof Rafter FSC 66.7 x 76.2 x 1079.5mm (42-1/2")
2pc. (1184) -
Peak Spacer FSC 73 x 152.4 x 177.8mm (7")
Y70229-1184
