Step 25: Attach Door Closer
Part 1
Hardware
4 x #10 x 1-1/4” Black Pan Screw
#10 x 1-1/4”
Black Pan
Screw
Components
1 x Bottom Tube Bracket
F25.1
(1142)
Closer Block
#10 x 1-1/4”
Black Pan
Screw
(1129) Top
Door Block
A: Measure 1” (2.54 cm) down from (1129) Top Door Block and 1/2” (1.27 cm) in from edge of (1142) Closer
Block then place Bottom Tube Bracket on (1142) Closer Block and (1130) Door Block, pre-drill with a 1/8” drill
bit then attach with four #10 x 1-1/4” Black Pan Screws. (F25.1)
1/2”
(1.27 cm)
1”
(2.54 cm)
Bottom Tube
Bracket
(1130)
Door Block
