Step 7: Attach Side Wall Sills
A: Place one (1107) Side Wall Sill on top of each (1152) Side Wall Panel. Use one (1188) Guide Spacer in the
grooves of each post and (1107) Side Wall Sill to line up posts with (1110) Mid Posts. Attach (1107) Side Wall
Sills to (1152) Side Wall Panels with three #8 x 3” Wood Screws per panel. Remove (1188) Guide Spacer. (F7.1
and F7.2)
Hardware
12 x #8 x 3” Wood Screw
(1107) Side
Wall Sill
Wood Parts
4 x (1107) Side Wall Sill
Post
(1152) Side
Wall Panel
(1110) Mid
Post
F7.1
F7.2
(1107) Side
Wall Sill
(1152) Side
Wall Panel
#8 x 3”
Wood Screw
Guide Spacers to sit in grooves
of Posts and Side Wall Sill to
align Side Wall Sill correctly,
then to be removed.
