Yardistry YM12842 - Step 8: Attach Corner Brackets

45 support@yardistrystructures.com
#10 X 1-1/4” Pan Screws
Connects Corner Bracket to bottom
4 corners.
Step 8: Attach Corner Brackets
Part 1
Hardware
8 x #10 x 1-1/4” Pan Screw
Components
4 x Corner Bracket
A: On the inside of the assembly, using one Corner Bracket per corner connect (1119) Front Base and
(1120) Back Base to (1118) Side Bases with two #10 x 1-1/4” Pan Screws per bracket. (F8.1 and F8.2)
#10 x 1-1/4”
Pan Screw
Corner
Bracket
(1118) Side
Base
(1119)
Front Base
(1120) Back
Base
#10 X 1-1/4” Pan Screws
Connects Corner Bracket to bottom
4 corners.
F8.1
F7.2
(1118) Side
Base
Front/Back
Base
(1118) Side
Base
F8.2
