Step 23: Door
Assembly
Part 3
E:
for the (1
175) Door Panel placement. (F23.6)
F:
Place (1
175) Door Panel in door opening and attach Square Hinges to Door Post with three #7 x 3/4” Wood
Screws per hinge. Remove (1
188) Guide Spacers. (F23.7 and F23.8)
(1
1
19)
Front Base
(1
188)
Guide
Spacer
Hardware
9 x #7 x 3/4” Wood Screw
(1
175) Door
Panel
Square
Hinge
#7 x 3/4”
Wood Screw
F23.6
F23.7
F23.8
Door
Post
Door
Post
Door
Post
