Slide the tongue from the SIDE WALL
into the groove of the FRONT POSTS
Rest FRONT WALL ASSEMBLY on the 4 x
4 Frame prior to sliding into SIDE WALL
ASSEMBLY
#10 x 4” Wood Screws -PRE-DRILL prior
Connect the FRONT WALL ASSEMBLY
to the SIDE WALLS
Slide the tongue from the SIDE WALL
into the groove of the FRONT POSTS
Rest FRONT WALL ASSEMBLY on the 4 x
4 Frame prior to sliding into SIDE WALL
ASSEMBLY
#10 x 4” Wood Screws -PRE-DRILL prior
Connect the FRONT WALL ASSEMBLY
to the SIDE WALLS
Step 5: Connect Wall Assemblies
Part 2
B: With a helper, stand up Front Wall
Assembly and slide so Side Wall

Post and (1109) Right Post. Pre-drill with a
1/8” drill bit then attach Front Wall Assembly
to Side Wall Assemblies with two #10 x 4”
Wood Screws per side. (F5.4 and F5.5)
Hardware
4 x #10 x 4” Wood Screw
F5.4
F5.5
Outside View
Side Wall
Assembly
Side Wall
Assembly
Front Wall
Assembly
(1109)
Right Post
(1108)
Left Post
Side Wall
Assembly
Front Wall
Assembly
#10 x 4”
Wood Screw
